Unmissable. Simple.

from 2.199 €/m²

Designed by LEDTEK Germany

Simply good.

LEDBRIX - The outdoor system

Developed by us and tested by TÜV. The system is perfectly suited for fixed installations. The special feature: The construction of the wall. The individual LED cabinets are quickly and easily integrated into a frame made of cast aluminium, which allows subsequent replacement without problems, even from the front. This front service eliminates the need to dismantle the entire wall for repair purposes. The LEDBRIX system makes it unmissable simple.

TÜV–approved / 48h Exchange service / Front mounting
3 Years Warranty / Developed in Germany
Statics for many sizes incl. / Slim and light
1 cable: all option / Easy installation
Self assembly possible / Content Player
Nearly infinitely expandable

Simply excellent.

TÜV-certified quality

LEDBRIX naturally complies with the EMC directive 2014/30/EU as well as the low voltage directive 2014/35/ EU. We guarantee safety, reliability and quality according to defined criteria, cabinets with 3 years warranty and competent support. The LEDBRIX system is a first-class DOOH solution.

Simply excellent.

TÜV-certified quality

LEDBRIX naturally complies with the EMC directive 2014/30/EU as well as the low voltage directive 2014/35/ EU. We guarantee safety, reliability and quality according to defined criteria, cabinets with 3 years warranty and competent support. The LEDBRIX system is a first-class DOOH solution

Ledbrix

100mm

Device depth
Other cabinets

500mm

Ledbrix

2.199€

Price/m²

Other cabinets

3.500€

Ledbrix

17,5 Kg

Weight/m²

Other cabinets

50 Kg

Simply bright.

Brilliant colour quality

With a luminosity of over 5,500 nits, the LEDBRIX wall is particularly suitable for producing a pin-sharp and bright image even on sunny days. Thanks to an IP protection rating of 65 on the front and rear, the LED wall can also withstand rain and snow.

Technical specifications

Cabinet

Pixel pitch

Cabinet weight

Light intensity

Protection class

Width x height

4.00 / 5.00 / 6.67 mm

3.55 kg

5.000 / 5.500 Nits

Front: IP 65, back: IP 54

640 x 320 mm

Viewing angle

Horizontal

Vertical

Viewing distance

140 degrees

120 degrees

5 meters

Simply quick.

Exchange service in 48h

Our LEDBRIX cabinets come in a specially designed cardboard box, which can also be used for our free 48h exchange service (within the warranty). Within 2 working days we will send you a new replacement panel free of charge. And by the way: LEDBRIX is available from stock, so you don’t have to wait too long!

Ordering process

OFFER

Use our configurator to create a non-binding offer according to your wishes. Choose between Customize: “Individual adaptation of the size of your outdoor facility” or Plug & Play: “All sizes including production drawing and static calculation for the frame substructure”.

BUILDING PERMIT

Use our offer to make a preliminary building enquiry/permission to build with your local authority. You will find a lot of useful information in our FAQ.

ORDER

Let us convince you of our excellent product and our unbeatable price and order by e-mail. The offer is directed exclusively to commercial customers and is subject to change. LedTek cabinets can only be used in other than private households. Errors and changes reserved.

CONSTRUCTION

You can order LEDBRIX cabinets optionally with a cast aluminium frame. A frame substructure is also required. The Plug & Play package includes a production drawing and a static calculation, which you would send to a metal construction company of your choice.

ASSEMBLY

It is possible to assemble LEDBRIX cabinets yourself in a simple and time efficient way. Due to the possibility of front mounting and due to the single cable system the installation effort is reduced to a minimum. Nevertheless, If questions should arise, we are at your disposal with technical support.

Configurator

Get your personalized quote now:
Address:

Company:

Full Name:

Street and No.:

Postal Code and City:

e-mail:


I hereby agree that my personal data will be stored and processed by JC Eventtechnik GmbH within the scope of preparing an offer. In accordance with the DSGVO, you are entitled at any time to request JC Eventtechnik GmbH to provide comprehensive information on the data stored about you. Furthermore, you can demand the correction, deletion and blocking of individual personal data. For further information, please refer to our data protection declaration at www.led-tek.de/datenschutz/.

Check inputs!

Thank you for your Request!

We have sent you a personal Quote to your e-mail adress! For further information feel free to contact us by Phone +49 551 492 493 44 or email at vertrieb@led-tek.de.



Statics & production drawing
Connection cable
Cast aluminium frame
Preconfigured video transmitter
Light sensor
Statics & production drawing
Connection cable
Cast aluminium frame
Preconfigured video transmitter
Light sensor

Brochure & Tips

BROCHURE

MANUAL

STATICS

Production drawings

Version 1:

2,56 x 3,52 M

Version 2:

2,28x 1,6 M

Version 3:

7,68 x 4,8 M

Version 4:

6,4 x 3,52 M

Version 5:

3,84 x 2,24 M

Version 6:

5,12 x 2,88 M

Version 7:

3,84 x 2,88 M

Version 8:

1,92 x 0,96 M

Download

NovaStar LCT

Software

Viplex Express

Software

RCFGX P6+

RCFGX P5

RCFGX P4
